Application
Can install few different screen nets to separate different sizes of rubber granules or rubber powder, etc.
Structure
It mainly consists of frame, motor, eccenter , link rod, screen net supporter, screen nets, etc.
Principle
Motor drive eccenter rotate as vibrating source, via link prod to pull and push the screen make reciprocating motion, so that different size of rubber or rubber powder will pass different screen net and go out from different outlets.
Specification and Prices
| Model | JYZZS-900 |
| Power: | 2.2kw |
| Dimension: | 4×0.9x1m |
| Weight: | 600kg |
| Shaft Rotation Speed: | 350rpm |
| Input: | Mixture of different size of Rubber Granule or Rubber Powder. |
| Output: | Separated different size of Rubber Granule or Rubber Powder. |
| Capacity: | 1000-1200kgs/hour |
| Delivery Lead Time: | 30days(Exclude Legal Holiday). |
| Price: | Please contact us to inquire |
Photo Gallery
Two outlet type JYZZS-900 Linear Vibrating Screen use in row
Three outlet type JYZZS-900 Linear Vibrating Screen in use
Five outlet type JYZZS-900 Linear Vibrating Screen in use
Another four outlet type JYZZS-900 Linear Vibrating Screen in Stock
