JYTP-700 Tire Block Pulverizer

JYTP-700 Tire Block Pulverizer

JYTP-700 Tire Block Pulverizer

Application

It is the machine to pulverize tire blocks or other rubber blocks into granules, the output size is controlled by screen nets, you can install different size of screen net to get different size of rubber granules.

Structure

Mainly consists of frame, motor, shaft, V-belt transmission system, feed hopper, pulverizing chamber, 16 rotating knives, 8 fixed blades, screen net, etc.

Principle

Feed material via the feeding hopper, the motor drive the main shaft and rotation knives rotate, to make relative motion with fixed blades, so that to shear the tire (rubber) blocks into granules till the granule come out through the screen net holes and be collected by the outlet hopper.

Specification and Prices

Model JYTP-700
Power: 45kw
Dimension: 2.5x2x2m
Weight: 5000kg
Input: ≤5cm Tire blocks or other rubber blocks
Output: ≤20mm Rubber granules mixed with steel wire or fly fiber.
Capacity: 2000-4000kgs/hour
Knife Quantity: 24pcs(16 rotation knives and 8 fixed knives)
Blade Material: YG10 Tungsten Steel
Knife Hardness: 92HRA
Delivery Lead Time: 30days(Exclude Legal Holiday).
Price: Please Contact us to inquire
 Photo Gallery
Manufacturing Photo of JYTP-700 Tire Block Pulverizer

Manufacturing Photo of JYTP-700 Tire Block Pulverizer

Knife of JYTP-700 Tire Block Pulverizer

Knife of JYTP-700 Tire Block Pulverizer

Belt Conveyor Collect Outlet of JYLP-1200 Tire Shredder and Feed To JYTP-700 Tire Block Pulverizer to Pulverize 5cm Tire Blocks to 1cm Tire Granules

Belt Conveyor Collect Outlet of JYLP-1200 Tire Shredder and Feed To JYTP-700 Tire Block Pulverizer to Pulverize 5cm Tire Blocks to 1cm Tire Granules

Photo of Input Material
4cm Tire blocks from JYQK-45 Tire Block Cutter

4cm Tire blocks from JYQK-45 Tire Block Cutter

Photo of Output Material
1cm Tire Granules from JYTP-700 Rubber Pulverizer

1cm Tire Granules from JYTP-700 Rubber Pulverizer

Video

Attention Please: When making this video, Whatsapp works well in China, but now it does not work in China, so that you can not contact us by Whatsapp, if you want co contact us, please click here to contact us by other ways.

From above video, you can see that there are some dust come out from the top, for ensuring clean workshop, you can install one JYC-100 Whirlwind Collecting Machine to collect the dust from the top.
