Application
This machine is designed to slice 2-120mm thick rubber tiles or EVA mat into thin rubber sheet, such as 1mm, 2mm, etc.
Structure
It is mainly consist of Base, Beam, Rollers, Knife belt, Knife Belt Wheels, Grinding wheel, Motor, etc.
Principle
Pinch roll feed rubber tiles in, the main motor drive the knife belt rotate to slice rubber tiles in the thin pieces or sheet according to output thickness setting, grinding wheels ensure the knife belt be always sharp.
Specification and Prices
| Model | JYPC-1350 |
| Power: | 11kw |
| Dimension: | 4200x1200x1800mm |
| Weight: | 3200kg |
| Input: | Thick Rubber or Foamed EVA or Other Flexible Plastic Tile or Mat or Sheet. |
| Output: | Thin Rubber or Foamed EVA or Other Flexible Plastic Mat or Sheet. |
| Maximum input thickness: | 120mm |
| Maximum input wide: | 1350mm for rubber tile. |
| Minimum output thickness: | 0.8mm |
| Delivery Lead Time: | 30days. |
| Price: | Please contact us to inquire |
Video Of How to Slice Rubber Tiles
