Unvulcanized Rubber Processing Machine

JYML Series Banbury Mixer

Photo of JYML Series Banbary Mixer

JYML Series Banbary Mixer

Application

It is mainly used for mixing natural rubber or reclaimed rubber with chemicals by kneading strength.

Structure

Mainly consists of frame, mixing chamber, two Rotor, roll sealing device, feeding & pressure feeding device, discharge device, gear reducer and motor, etc

Principle

When it work, two Rotors make relative rotation, the feeded material be clamped into the gap between Rotors and conteniously be kneaded and sheared by two Rotor, up & bottom pegs and chamber wall, cause the material temperature rise sharply, viscosity reduce, surface wettability increase, so that good contact between rubber and Additive.

Specification and Prices

Item JYML-35 JYML-55 JYML-75 JYML-110
Chamber Volume: 75L 125L 180L 250L
Effective Mixing Volume: 35L 55L 75L 110L
Kneading Motor Power: 55Kw 75Kw 110Kw 185Kw
Hopper Tilting Motor: 5.5Kw 5.5Kw 5.5Kw 7.5Kw
Hopper Tilting Angle: 110o 110o 110o 110o
Front Rotor Rotation Speed: 36rpm 36rpm 36rpm 30rpm
Back Rotor Rotation Speed: 30rpm 30rpm 30rpm 24.5rpm
Compressed Air Pressure: 0.6-0.8Mpa 0.6-0.8Mpa 0.6-0.8Mpa 0.6-0.8Mpa
Cooling Water Pressure: 0.3-0.4Mpa 0.3-0.4Mpa 0.3-0.4Mpa 0.2-0.4Mpa
Dimension: 3150x1900x2880mm 3280x2120x3090mm 3250x2210x3250mm 4075x2712x3580mm
Price(FOB Qingdao,China): Please contact us to inquire Please contact us to inquire Please contact us to inquire Please contact us to inquire
