Do you want to know how to remove tire bead from whole tire? – JYLS-1200 Tire Debeader

JYLS-1200 Tire Debeader

JYLS-1200 Tire Debeader

Below video show how to do it by our JYLS-1200 Tire Debeader.

Do you know how to remove tire bead by JYLS 1200 Tire Debeader

If this machine is not the one you want, welcome to see other machines with similar function by click JYLS-750 Tire Debeader or JYNQ-1200 Tyre Debeader(Separator).

Application

Adopts Hydraulic as power, used to draw tire bead thick steel wire from Tires≤1200mm in diameter.

Structure

This is machine consists of motor, oil tank, hydraulic cylinder, extracting hook, extracting mouth, machine frame, etc.

Principle of JYLS-1200 Tire Debeader

The motor drive the hydraulic cylinder making reciprocating motion, so that to extract the tire bead thick steel wire out.

Specification of JYLS-1200 Tire Debeader

Model JYLS-1200
Power: 11kw
Dimension: 4.3×0.9×1.6m
Weight: 1200kg
Input: Tires≤1200mm in diameter
Output: ≤1200mm Torn Tire and Tire Bead Thick Steel Wires
Capacity: 20-30Tires/hour
Plunger Piston Maximum Stroke: 1200mm
Maximum Size Tires: 1200mm in diameter.
Maximum Drawing force: 130Kilonewton.
Max Reciprocating Motion Frequency: 1.5cycle/minutes
Delivery Lead Time: 30days(Exclude Legal Holiday).
Price: Please contact us to inquire
Tire lift cylinders of JYLS-1200 Tire Debeader, which is being manufactured.
Tire lift cylinders, which is being manufactured.
JYLS-1200 Tire Debeader being manufactured in our factory.
Still being manufactured.
Just finished JYLS-1200 Tire Debeader
Just being manufactured
