First of all, please watch the video how this tire cutting machine works.
Application
Cut tires(up to 120cm) into tire sections. Can cut Radia tires, Half-Radial tires and Fiber tires, the tires, no matter with tire bead or already removed bead.
Structure
Mainly consist of Motor, Hydraulic System, Cylinders, Knives, Frame, Material Cutting Part, Fixed Blade and Rotating Blade, etc.
Principle of JYLQ-1200 Tire Cutting Machine
Motor drive two cylinders work, one cylinder drive the catching part catch the tires stably, then the other cylinder drive the rotating knives move to the fixed knives, so that to shear the tires.
Specification of JYLQ-1200 Tire Cutting Machine
| Model | JYLQ-1200 |
| Power: | 5.5kw |
| Dimension: | 1.9*1.1*1.7m |
| Weight: | 2000kg |
| Input: | Debeaded Tires≤1400mm in diameter |
| Output: | Tire sections. |
| Capacity: | 1500-2500kg/hour |
| Knife Quantity: | 4pcs |
| Knife Material: | DC53 Alloy |
| Knife Hardness: | 62HRC |
| Cutting Speed: | 2-3 times per minutes. |
| Catching pressure: | 3 ton. |
| Cutting pressure: | 25 ton. |
| Delivery Lead Time: | 10days(Exclude Legal Holiday). |
| Price: | Please contact us to inquire |
