Application
At normal temperature, shred car tires into 3cm wide tire scraps directly, due to the knives are hexagon fly saucer shape, no need rotation screen, the shredding speed very fast.
Structure
Frame, Motor, Gear Reducer, Shredding Chamber, Shredding Shafts, Shredding Knives, etc.
Principle
Motor drive two shredding draft rotate at opposite direction, so that the shredding knives can shred the material in the shredding chamber.
Specification and Price
| Model | JYLP-750 |
| Power: | 15*2=30kw |
| Dimension: | 3.4×1.2×2.2m |
| Weight: | 4000kg |
| Input: | Car Tires≤750mm in diameter |
| Output: | ≤3cm wide tire scraps |
| Capacity: | 1000-1500kg/hour |
| Blade Qty: | 3cm thick,25pcs |
| Blade Speed: | 18rpm |
| Blade Material: | Cr12MoV. |
| Blade Picture: | |
| Delivery Lead Time: | 30days |
| Price: | Please contact us to inquire |
Knife Photo
Shredding Knife of JYLP-750 Car Tire Shredder
