Application
Used to press rubber, mix rubber, roll the rubber material to pieces by two rolling rolls.
Structure
Mainly consists of base, frame, motor, gear reducer, gears, front and rear rolls, temperature-adjusting device, safety switches, electric control system, etc.
Principle
Motor through gear reducer and gears drive two rolls make relative movement, to press, mix and roll the rubber material to rubber pieces.
Specification and Prices
| Model No. | XK-160 | XK-230 | XK-250 | XK-300 | XK-360 | XK-400 | XK-450 | XK-560 | XK-550B | XK-610 | XK-660 | XK-710 |
| Roll Working Diameter(mm) | 160 | 230 | 250 | 300 | 360 | 400 | 450 | 560
/510 |
550 | 610 | 660 | 710 |
| Roll Working Length(mm) | 320 | 600 | 620 | 750 | 900 | 1000 | 1200 | 1530 | 1500 | 1930 | 2130 | 2200 |
| Front Roll Line
Speed(m/min) |
9 | 10.21 | 16.3 | 15.1 | 16.7 | 18.65 | 21.8 | 26.4 | 22.5 | 27.3 | 28 | 31.9 |
| Speed Ratio | 1:1.35 | 1:1.19 | 1:1.17 | 1:1.25 | 1:1.25 | 1:1.27 | 1:1.27 | 1:1.22 | 1:1.2 | 1:1.2 | 1:1.24 | 1:1.51 |
| Max Gap Between Two Rolls(mm) | 4.5 | 7 | 8 | 10 | 10 | 10 | 15 | 15 | 16 | 15 | 15 | 15 |
| Capacity
Per Batch(kg) |
1~2 | 6~10 | 8～15 | 15~20 | 20~25 | 18～35 | 25～50 | 50～60 | 50～65 | 140 | 165 | 190 |
| Power(kw) | 5.5 | 15 | 18.5 | 22 | 30 | 37 | 55 | 90 | 110 | 160 | 180 | 180 |
| Dimension
L*W*H(mm) |
1080*
796* 1415 |
2800*
1200* 1120 |
3400* 1800* 1500 |
3580*
1550* 1695 |
3780*
1850* 1750 |
4350* 1850* 1780 |
5200* 2390* 1770 |
6120* 2280* 2000 |
6646* 2736* 2105 |
6575*
2910* 1800 |
7460* 3660* 2080 |
8185*
3910* 2270 |
| Weight(kg) | 1100 | 1300 | 3500 | 5200 | 6500 | 7860 | 13000 | 22500 | 22500 | 44000 | 49500 | 59000 |
| Price(FOB Qingdao,China) | USD
4000 |
USD
6000 |
USD
7000 |
USD
10000 |
USD
13000 |
USD
15000 |
USD
22000 |
USD
38000 |
USD
65000 |
USD
101000 |
USD
110000 |
USD
210000 |
| Production Lead Time（day） | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 |
