JYFD Series Self Dumping Hopper Conveyor
Application
JYFD Series of Self Dumping Hopper Conveyors are mainly used to convey bulk material in batch, for example, completely convey one batch of kneaded rubber material to open type rubber mixing machine, etc.
Structure
This machine mainly consists of frame, hopper, hopper rail, motor, gear, chain, and electrical control panel, etc.
Principle
Electrical control panel control the motor run to drive the gear and chain rotate, the chain draw the hopper go up and down along the hopper rails, the hopper rail is arc shape, when the hopper reach the top, the hopper will dump the material to next machine by gravity force.
Specification and Prices
| Model No. | JYFD-35 | JYFD-55 | JYFD-75 | JYFD-110 |
| Motor Power | 1.5kw | 1.5kw | 2.2kw | 2.2kw |
| Hopper Capacity | 35L | 55L | 75L | 110L |
| Each Batch Lifting Time | 20 Seconds | 20 Seconds | 24 Seconds | 24 Seconds |
| Dimension | 3.16×0.55×1.7m | 3.16×0.55×1.7m | 3.62×0.75×1.95m | 3.62×0.75×1.95m |
| Weight | 1050kgs | 1100kgs | 1150kgs | 1200kgs |
| Production Lead time | 15days | 15days | 15days | 15days |
| Price | Please contact us to inquire
|
Please contact us to inquire | Please contact us to inquire | Please contact us to inquire |
Photo Gallery
JYFD Series of Self Dumping Hopper Conveyors in Stock
JYFD Series of Self Dumping Hopper Conveyor used to lift the material from Banbury Rubber Mixer to Open Type Rubber Mixing Mill
