Application
It adopts Strong Permanent Magnet fabricate magnetic core, ideal to pick out Iron/Steel particles from rubber granule or rubber powder recycled from used tires. This magnetic separator is very suitable to be installed on narrow places, etc.
Structure
It mainly consists of feeding hopper, frame, motor, magnetic core, rotating roll and transmission chain, etc.
Principle
When the material falling inside from the hopper, the magnetic core will suck the Iron/steel particles to the rotating roll, Motor drive the rotating roll rotate to remove the Iron/steel particle and release them to the Iron/Steel Outlet.
Specification and Prices
| Model | JYCX-201 |
| Power: | 0.75kw |
| Dimension: | 0.7×0.4×0.7m |
| Weight: | 110kg |
| Rotating Roll Diameter: | 200mm |
| Rotating Roll Speed: | 46rpm |
| Input: | ≤Mixture of Rubber Crumb and Iron/Steel Particle. |
| Output: | ≤Separated Rubber Crumb and Iron/Steel Particle. |
| Capacity: | 500-1000kgs/hour |
| Magnetic Roll Quantity: | 1pcs |
| Magnet Type: | Strong Magnet |
| Delivery Lead Time: | 20days(Exclude Legal Holiday). |
| Price: | Please Contact us to inquire |
Photo Gallery
Just Finished JYCX-201 Single Core Magnetic Separator
One JYCX-201 Single Core Magnetic Separator Installed Above A Screw Conveyor, for this narrow space, it is the ideal machine to separate Iron/Steel particles before falling to the screw conveyor.
