Application
Used to cut Car Tires Tread Rings into Car Tire Tread Belt, also can be used to cut other rubber products in small pieces.
Structure
Mainly consists of frame, motor, gear reducer, shafts, Chain wheel,Chain, coupling,and Cutting Disc Knives, etc.
Principle
The motor via reducer drive two disc knives making relative motion to shear car tire tread rings into car tire tread belt or shear other rubber products into rubber pieces.
Specification and Prices
Model | JYCD-25 |
Power: | 3kw |
Dimension: | 0.8×0.7×1.3m |
Weight: | 700kg |
Input: | Car tire tread rings or other rubber products. |
Output: | Car tire tread belts or rubber scraps. |
Capacity: | 300-600car tire treads per hour. |
Disc Knife Dimension: | Φ250x20mm |
Knife Quantity: | 2pcs |
Blade Material: | Tungsten Steel |
Blade Hardness: | 92 HRA |
Knife Rotation Speed: | 100rpm |
Delivery Lead Time: | 10days(Exclude Legal Holiday). |
Price: | Please contact us to inquire |
